產品規格

Video Interface

Video Ports

Camera Link - up to 3x Base, 1x Medium + 1x Base, 1x Full + 1x Base (bi-directional)
LVDS - 11 signals per MDR-26 connector (bi-directional)
3 MDR-26 Connectors

Maximum Pixel Clock Frequency

Camera Link - 85MHz

LVDS - 100 MHz

Camera Readout Formats

Area and line scan

Pixel Formats

Monochrome - 8 to 16 bits
Color - Bayer, RGB (24, 30, 36 and 48 bit)
Other formats supported on request

Acquisition from Multiple Cameras

Record up to 3 cameras.
Hardware-synchronized recording across multiple units.

Triggering Input/Output

LVDS - 2 outputs, 2 inputs
TTL - 10 bi-directional lines
Camera Link CC lines

Frame Time Stamping

Every recorded frame is time tagged by hardware time-code generator
Time-code resolution is 100 nanoseconds
Time-code generator can be synchronized to external IRIG, GPS or other timing device

Video Storage

Hard Drive Interface

(1) or (3) 4G Fibre Channel SFP (optical) interfaces

Hard Drive Compatibility

Contact IO Industries for current manufacturers and firmware levels

Max Sustained Recording Rate

1125 MByte per second

Maximum Storage Capacity

350 Petabytes (2⁵⁰)

RAID Configurations

RAID levels 0, 1(0+1) and 3
Other levels possible using 3rd party external drive arrays

Storage configuration

Flexible and scalable to accommodate any application
Contact IO Industries for details

System Peripherals

2 USB Ports
2 RS-232 Ports
10/100 Ethernet
VGA output up to 1920x1440@85 Hz
Microphone Input/Stereo Line Out
Optional GPS Receiver

Mechanical

Dimensions

11.4" x 1.7" x 7.6" (290 x 43 x 192 mm)

Weight

2.8 lbs (1.3 Kg)

Case

Lightweight aluminum

Power

12V DC, 45W Max.
