| Digital Parts |
Resolution |
5 Mega Pixel |
| Photo Resolution |
2560X1920-1600X1200 |
| Video Resolution |
640X480 |
| Sensor Size |
1/2.5 Inches |
| LCD Screen |
8 Inches TFT Screen, Resolution is 800X 600 |
| Video Output |
AV Output (NTSC/PAL) |
| Data Output |
USB2.0 |
| Menu Language |
Chinese / English |
| Storage |
SD Card Slot with Optional Memory Cards (Maximal Storage Capacity is 4G) |
| Scene Mode |
Standard / Softness / Vivid |
| Exposure Mode |
Auto Exposure |
| Date Mode |
Year, Month, Day, Hour, Minute |
| Optical Parts |
Viewing Head |
Compensation Free Binocular Head, Inclined at 30° |
| Eyepiece |
Wide Field Eyepiece WF10×/ 18 |
| Objective |
Achromatic Objective 4×、10×、40×、100× |
| Nosepiece |
Quadruple Nosepiece |
| Condenser |
NA 1.25 Abbe Condenser with Iris Diaphragm and Filter |
| Focusing System |
Coaxial Coarse & Fine Adjustment |
| Stage |
Double Layers Mechanical Stage 140×140mm/ 75×50mm |
| Illumination |
Halogen Lamp 6V/ 20W, Brightness Adjustable |
| Filter |
Blue & Green Filter |
| Dark Field Attachment |
Dark Field Condenser (Dry) |
| Dark Field Condenser (Oil) |
| Fluorescent Attachment |
Epi-fluorescent Attachment |
| Optional Parts |
Phase Contrast Kit |
Single Phase Contrast Kit |
| Sliding Phase Contrast Kit |
| Turret Phase Contrast kit |
| Polarization Set |
Simple Polarization Set |
